Crane Hook Block – Single Sheave
We supply Irizar Forge forged crane hook blocks that meet Australian and international standards and can also manufacture hook blocks to your exact specifications. Irizar Forge crane hooks are suitable for crane hook replacements for all major crane brands.
To place an order or discuss your requirements please call 1300 869 653.
| Weight (kg) | General Dimensions | Drive Groups & Loads (kg) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hook Num. | Rope Diam. | ØP | D | V | M | S | 1BmM3 | 1AmM4 | 2mM5 | 3mM6 | 4mM7 | 5mM8 | |
| 12 | 0.8 | 7 | 160 | - | 120 | 285 | 105 | 2000 | 1600 | 1250 | 1000 | 800 | 630 |
| 20 | 1.6 | 10 | 200 | - | 140 | 345 | 131 | 4000 | 3200 | 2500 | 2000 | 1600 | 1250 |
| 36 | 2.5 | 15 | 280 | - | 155 | 435 | 180 | 6300 | 5000 | 4000 | 3200 | 2500 | 2000 |
| 79 | 5 | 16 | 355 | - | 195 | 520 | 223 | 12500 | 10000 | 8000 | 6300 | 5000 | 4000 |
| 126 | 6 | 22 | 450 | - | 240 | 631 | 274 | 16000 | 12500 | 10000 | 8000 | 6300 | 5000 |
