Entertainment Grade-8 Eye Bolts
Townley’s new range of Entertainment Rigging Eye Bolts are based on our standard Grade 8 Eye Bolt, but finished in a black matt colour for low visibility applications. The larger internal eye diameter offers a versatile alternative to standard Grade 4 eyebolts.
- Forged From High Tensile Alloy Steel
- Tempered
- Black Zinc Low Sheen Matt Finish
- Manufactured from steel certified to Australian Standards
- 100% Electromagnetic crack testing to AS 1171
- Long shanks and special thread forms available upon request
| Type | WLL F1 (t) | WLL F2 (t) | Size | B | C | D | E | G | L | Weight (kg) | Product Code | CAD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Metric Coarse | 1 | 0.25 | M10 | 27 | 30 | 12 | 48 | 10 | 21 | 0.17 | ER-HTEB10 | Register |
| Metric Coarse | 1.6 | 0.4 | M12 | 27 | 30 | 12 | 48 | 10 | 21 | 0.17 | ER-HTEB12 | Register |
| Metric Coarse | 4 | 1 | M16 | 34 | 34 | 15 | 56 | 14 | 28 | 0.37 | ER-HTEB16 | Register |
| Metric Coarse | 6 | 1.6 | M20 | 41 | 40 | 17 | 70 | 16 | 35 | 0.6 | ER-HTEB20 | Register |
| Metric Coarse | 7 | 2 | M22 | 50 | 50 | 20 | 70 | 16 | 42 | 1.1 | ER-HTEB22 | |
| Metric Coarse | 8 | 2.5 | M24 | 50 | 50 | 20 | 85 | 18 | 42 | 1.1 | ER-HTEB24 | Register |
