Eyebolt Longshank

Grade-4 Long Shank Eyebolts

Category:

  • 6:1 Safety Factor
  • Manufactured using only heat certified Australian Steel

Available on Request:

  • Special Thread Forms
  • Hot Dip Galvanizing, Zinc Passivating, Zinc Plating, Chrome Plating, Powder Coating
  • Testing and Certification
TypeWorking Load Limit (t)SizeThread PitchBCDELProduct CodeCAD
Metric Coarse0.25M101.528241125As RequiredEBLSM10
Metric Coarse0.4M121.7528241125As RequiredEBLSM12
Metric Coarse0.8M16234281640As RequiredEBLSM16
Metric Coarse1.6M202.544322044As RequiredEBLSM20
Metric Coarse2M222.550332044As RequiredEBLSM22
Metric Coarse2.5M24357382251As RequiredEBLSM24
Metric Coarse2.5M27371482865As RequiredEBLSM27
Metric Coarse4M303.571482865As RequiredEBLSM30
Metric Coarse5M333.571482865As RequiredEBLSM33
Metric Coarse6.3M36486553373As RequiredEBLSM36
Metric Coarse7M39486553373As RequiredEBLSM39
Metric Coarse8M424.5102664090As RequiredEBLSM42
Metric Coarse10M485115724999As RequiredEBLSM48
Metric Coarse15M565.51439556124As RequiredEBLSM56
Metric Coarse20M6461439556124As RequiredEBLSM64
Metric Coarse25M72616310666140As RequiredEBLSM72
Metric Coarse30M76616310666140As RequiredEBLSM76
Imperial BSW0.253/8"1628241125As RequiredEBLSW375
Imperial BSW0.41/2"1328241125As RequiredEBLSW500
Imperial BSW0.85/8"1134281640As RequiredEBLSW625
Imperial BSW1.63/4"1044322044As RequiredEBLSW750
Imperial BSW27/8"950332044As RequiredEBLSW875
Imperial BSW2.51"857382251As RequiredEBLSW1000
Imperial BSW51 1/4"771482865As RequiredEBLSW1250
Imperial BSW71 1/2"686553373As RequiredEBLSW1500
Imperial UNC0.253/8"1628241125As RequiredEBLSU375
Imperial UNC0.41/2"1328241125As RequiredEBLSU500
Imperial UNC0.85/8"1134281640As RequiredEBLSU625
Imperial UNC1.63/4"1044322044As RequiredEBLSU750
Imperial UNC27/8"950332044As RequiredEBLSU875
Imperial UNC2.51"857382251As RequiredEBLSU1000
Imperial UNC51 1/4"771482865As RequiredEBLSU1250
Imperial UNC71 1/2"686553373As RequiredEBLSU1500
