Swivel Hooks Heavy Duty
ELD Swivel Hooks are designed and manufactured by an experienced team based in Milan. The Swivel Hooks are available in two models, including a light-duty version, suitable for common applications, and heavy-duty version for more severe environmental conditions.
- Forged – hardened and tempered
- Heavy duty bearings
- Load rated
- Based on BS 2903
| WLL (kg) | Chain (mm) | A | B | C | D | D1 | E | F | H | L | M | N | P | R | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8.0t Grade 8 | 16 | 17.5 | 65 | 165 | 51 | 43 | 49 | 37 | 62 | 266 | 72 | 120 | 70 | 24 | 5.87 |
| 11.5t Grade 8 | 19 | 22 | 68 | 198 | 58 | 53 | 60 | 43 | 75 | 310 | 82 | 136 | 82 | 27 | 9.75 |
| 16.0t Grade 8 | 22 | 24 | 84 | 222 | 66 | 58 | 67 | 52 | 84 | 352 | 92 | 154 | 92 | 31 | 15.3 |
| 22.0t Grade 8 | 26 | 29 | 107 | 283 | 87 | 78 | 80 | 64 | 110 | 434 | 115 | 191 | 108 | 38 | 26.5 |
| 31.5t Grade 8 | 32 | 34 | 117 | 339 | 97 | 87 | 94 | 80 | 120 | 512 | 132 | 222 | 132 | 45 | 50 |
